130° TROCHANTRIC FEMUR NAIL
Specification
- Rotational stability: Combining a hip pin which provides rotational stability with a load-bearing femoral neck screw ensures intra- and postoperative safety.
- Insertion safety stop: The screw shoulder prevents the femoral neck screw from undesired slippage through the nail into the femoral neck.
- An anatomical angle of 6° allows the nail to be inserted and positioned in the medullary canal with ease.
- PFN Nail (Proximal Femoral Nail) diameters of 9, 10, 11 and 12 mm permit insertion without reaming allowing a simplified, time saving surgical procedure with less blood loss.
- A choice of static or dynamic interlocking. The distal interlocking slot makes primary or secondary axial dynamization possible.
- The nail’s distal flexibility and optimal distance between the interlocking bolt and the tip of the nail minimize stress concentration and tension in the femoral shaft.
SIZES
- PFN Nail (Proximal Femoral Nail) Short sizes: Distal diameter 9-13 mm, Angle 130° or 135°, Length from 180 to 240 mm. Available in both stainless Steel and Titanium.
- PFN Nail (Proximal Femoral Nail) Long sizes: Distal diameter 9-13 mm, Angle 130° or 135°, Length from 300 to 420 mm. Available in both stainless Steel and Titanium. Proximal Femoral Nail available for both Left and Right.
- 4.9 mm Locking Bolt Sizes: Length from 22 to 100 mm in both stainless Steel and Titanium.
- 6.4 mm Bolt Sizes: Length from 55 to 130 mm in both stainless Steel and Titanium.
- 8 mm Bolt Sizes: Length from 70 to 120 mm in both stainless Steel and Titanium.
