5.0MM CANCELLOUS LOCKING HEAD SCREW
Specification
- Cancellous Screws available lengths are 10mm, 12mm, 14mm, 16mm1, 18mm, 20mm, 22mm, 24mm, 26mm, 28mm, 30mm, 32mm, 34mm, 36mm, 38mm, 40mm, 42mm, 44mm, 46mm, 48mm, 50mm, 55mm, 60mm, 65mm, 70mm, 75mm, 80mm, 85mm, 90mm, 95mm, 100mm, 105mm, 110mm, 115mm and 120mm.
- Screw is made from pure Titanium and SS 316L.
- Low-profile head helps reduce possibility of soft tissue irritation.
- Reverse-cutting flutes assist in screw removal.
- Choice of thread lengths offers best fit of threads into far bone fragment, for greater interfragmentary compression.
- Cancellous thread profile uses deep cutting threads with a large pitch to increase resistance to pullout. The large pitch also accelerates screw insertion and removal.
- Self-drilling, self-tapping screw tip facilitates screw insertion by eliminating the need for predrilling and tapping in most cases.
- Any additional length sizes of this screw will be made on demand.
- This is Self Tapping Screw. Self Tapping Screws cuts its own thread while being driven into the bone. It makes a small hole while entering the bone which creates a tight friction fit between the threads. This helps fight vibration loosening and allows the parts to be taken apart if needed
Uses
Cancellous Screws are designed specifically for use in the spongy, less dense, and trabecular bone tissue, commonly found at the ends of long bones, such as the femur and the tibia.
This Screw is also indicated for:
- Femoral neck fractures
- Slipped capital femoral epiphyses
- Tibial plateau fractures
- Ankle arthrodeses
- Pediatric femoral neck fractures
- Intercondylar femur fractures
- Sacroiliac joint disruptions
- Subtalar arthrodeses
